  • DIN
    Dynamic Power

  • • 100% maintance free
    • Enveloped Separator for low electric resistance Reliable starting power

    • Special Tissue for improvement of durability
    • Safety and reliability due to restraint to an inflow of outside sparks
    • Ultramicro fiber & Special tissue to increase durability of plate by reducing aging –rate of active material.
    • Reliable starting power
    • Excellent electrical performance (Minimum-self discharge)

DIN Gr.No Catalogue No.
 CAPACITY CCA(SAE)
 Dimension(mm) Layout Terminal Hold-down
20HR L W H TH
LB1 MF53646 36 330 208 174 175 175 0 A B13
LB1 MF54321 45 450 208 174 175 175 0 A B13
L1 MF54459 44 390 208 174 190 190 0 A B13
L1 MF55054 50 420 208 174 190 190 0 A B13
LB2 MF54519 45 390 242 174 175 175 0 A FIXED B4
LB2 MF55046 50 450 242 174 175 175 0 A B13
LB2 MF55457 54 480 242 174 175 175 0 A B13
LB2 MF56077 60 510 242 174 175 175 0 A B13
L2 MF55559 55 480 242 174 190 190 0 A B13
L2 MF56219 62 540 242 174 190 190 0 A B13
LB3 MF55415 54 480 277 174 175 175 0 A B13
LB3 MF56318 63 540 277 174 175 175 0 A B13
LB3 MF56828 68 570 277 174 175 175 0 A B13
LB3 MF57113 72 640 277 174 175 175 0 A B13
L3 MF56638 66 540 277 174 190 190 0 A B13
L3 MF57219 72 610 277 174 190 190 1 A B13
L3 MF57412 74 680 277 174 190 190 0 A B13
LB4 MF57539 75 640 315 174 175 175 0 A B13
L4 MF58043 80 640 315 174 190 190 0 A B13
LB5 MF58515 85 720 354 174 175 175 0 A B13
L5 MF58827 88 680 354 174 190 190 0 A B3
L5 MF59218 92 720 354 174 190 190 0 A B3
L5 MF60038 100 850 354 174 190 190 0 A B3
B19 MF53504 35 330 187 136 200 220 0 B B1
B19 MF54026 40 360 187 127 200 220 0 B 　
B24 MF54523 45 360 234 127 200 220 0 A 　
D20 MF55041 50 390 200 172 200 220 0 A B1
D23 MF56068 60 480 230 172 200 220 0 A 　
D26(G24) MF56048 60 480 266 172 200 220 0 A B9
D26(G24) MF57024 70 540 266 172 200 220 1 A B9
D31 MF57512 75 600 302 172 200 220 0 A 　
D31 MF58513 85 680 302 172 200 220 0 A 　
D31 MF59518 95 720 302 172 200 220 0 A B1
D31 MF60045 100 760 302 172 200 220 0 A B1
