  • BCI
    Dynamic Power

  • • 100% maintance free
    • Enveloped Separator for low electric resistance Reliable starting power

    • Special Tissue for improvement of durability
    • Safety and reliability due to restraint to an inflow of outside sparks
    • Ultramicro fiber & Special tissue to increase durability of plate by reducing aging –rate of active material.
    • Reliable starting power
    • Excellent electrical performance (Minimum-self discharge)


BCI Gr.No Catalogue No.
 CAPACITY CCA(SAE)
 Dimension(mm) Layout Terminal Hold-down
20HR L W H TH
51(R) MF51-430 71 430 234 136 200 220 10 A B1
51( R) MF51-460 78 460 234 136 200 220 10 A B1
21( R) MF21-450 80 450 200 172 200 220 10 A B1
21( R) MF21-500 88 500 200 172 200 220 10 A B1
26( R) MF26-450 80 450 208 172 180 200 10 A B1
26( R) MF26-550 100 550 208 172 180 200 10 A B1
85( R) MF85-500 85 500 230 172 180 200 11 A B1
85( R) MF85-550 90 550 230 172 180 200 11 A B1
34( R) MF34-550 100 550 260 172 180 200 10 A B1
34( R) MF34-630 125 630 260 172 180 200 10 A B1
34( R) MF34-670 130 670 260 172 180 200 10 A B1
34( R) MF34-710 140 710 260 172 180 200 10 A B1
34( R) MF34-750 155 750 260 172 180 200 10 A B1
25(35) MF25-550 100 550 230 172 200 220 10 A B1
25(35) MF25-580 110 580 230 172 200 220 10 A B1
24( R/F) MF24-450 80 450 257 172 200 220 10 A B1
24( R/F) MF24-500 90 500 257 172 200 220 10 A B1
24( R/F) MF24-550 100 550 257 172 200 220 10 A B1
24( R/F) MF24-600 113 600 257 172 200 220 10 A B1
24( R/F) MF24-630 130 630 257 172 200 220 10 A B1
24( R/F) MF24-680 140 680 257 172 200 220 10 A B1
24( R/F) MF24-750 155 750 257 172 200 220 10 A B1
27( R/F) MF27-630 130 630 302 172 200 220 10 A B1
27( R/F) MF27-670 140 670 302 172 200 220 10 A B1
27( R/F) MF27-750 155 750 302 172 200 220 10 A B1
27( R/F) MF27-810 180 810 302 172 200 220 10 A B1
27( R/F) MF27-840 190 840 302 172 200 220 10 A B1
30H MF30H-900 182 830 325 172 200 220 10 A B1
31(S) MF31-630 130 630 330 172 218 242 18 TOP 　
31(S) MF31-700 150 700 330 172 218 242 18 TOP 　
31(S) MF31-750 160 750 330 172 218 242 18 TOP 　
31(S) MF31-800 170 800 330 172 218 242 18 TOP 　
31(S) MF31-850 180 850 330 172 218 242 18 TOP 　
31(S) MF31-1000 190 1000 330 172 218 242 18 TOP 　
58( R) MF58-460 75 460 236 182 157 178 26 A B8
58( R) MF58-500 90 500 236 182 157 178 26 A B8
58( R) MF58-560 100 560 236 182 157 178 26 A B8
65( R) MF65-650 130 650 294 187 171 191 10 A B8
65( R) MF65-750 140 750 294 187 171 191 10 A B8
70(DT) MF70-400 71 400 208 179 180 180 17 SIDE B1
70(DT) MF70-450 80 450 208 179 180 180 17 SIDE B1
70(DT) MF70-500 90 500 208 179 180 180 17 SIDE B1
70(DT) MF70-550 100 550 208 179 180 180 17 SIDE B1
75(DT) MF75-500 90 500 230 179 180 180 17 SIDE B1
75(DT) MF75-550 100 550 230 179 180 180 17 SIDE B1
75(DT) MF75-600 113 600 230 179 180 180 17 SIDE B1
75(DT) MF75-630 125 630 230 179 180 180 17 SIDE B1
75(DT) MF75-650 130 650 230 179 180 180 17 SIDE B1
78(DT) MF78-550 100 550 260 179 180 180 17 SIDE B1
78(DT) MF78-600 113 600 260 179 180 180 17 SIDE B1
78(DT) MF78-630 125 630 260 179 180 180 17 SIDE B1
78(DT) MF78-670 130 670 260 179 180 180 17 SIDE B1
78(DT) MF78-710 140 710 260 179 180 180 17 SIDE B1
78(DT) MF78-750 155 750 260 179 180 180 17 SIDE B1
90 (LB2) MF90-450 80 450 242 174 175 175 24 A B13
90 (LB2) MF90-500 90 500 242 174 175 175 24 A B13
90 (LB2) MF90-550 100 550 242 174 175 175 24 A B13
47 (L2) MF47-500 90 500 242 174 190 190 24 A B13
47 (L2) MF47-600 110 600 242 174 190 190 24 A B13
91 (LB3) MF91-580 100 580 277 174 175 175 24 A B13
91 (LB3) MF91-630 110 630 277 174 175 175 24 A B13
91 (LB3) MF91-690 130 690 277 174 175 175 24 A B13
48 (L3) MF48-580 100 580 277 174 190 190 24 A B13
48 (L3) MF48-630 110 630 277 174 190 190 24 A B13
48 (L3) MF48-690 130 690 277 174 190 190 24 A B13
49 (L5) MF49-750 160 750 354 174 190 190 24 A B13
49 (L5) MF49-850 180 850 354 174 190 190 24 A B13
94R (L4) MF94R-680 140 680 315 174 190 190 24 A B13
92 (LB4) MF92-650 125 650 315 174 175 175 24 A B13
93 (LB5) MF93-800 140 800 354 174 175 175 24 A B13
MINIFIT MF MINIFIT 65 400 243 127 180 200 　 A B6
22F MF22F-450 75 450 240 172 180 205 11F DUAL Y B9
22F MF22F-500 90 500 240 172 180 205 11F DUAL Y B9
22F MF22F-550 95 550 240 172 180 205 11F DUAL Y B9
