Tire Size |
Max Load |
RIM |
Section Width |
Overall Diameter |
Tread Depth |
SLR. |
S/W | UTQG | |||||||||||
WEAR | TRAC. | TEMP. | |||||||||||||||||
lbs | kgs | MEASURING | APPROVED | mm | inch | mm | inch | mm | /32'' | mm | |||||||||
15 inch |
* | 165/55R 15 | 75 | V | 853 | 387 | 5.0 | 4.5~6.0 | 170 | 6.7 | 563 | 22.2 | 6.2 | 7.8/32 | 261 | BSW | - | - | - |
14 inch |
* | 165/55R 14 | 72 | V | 783 | 355 | 5.0 | 4.5~6.0 | 170 | 6.7 | 538 | 21.2 | 6.2 | 7.8/32 | 249 | BSW | - | - | - |
* | 155/65R 14 | 75 | S | 853 | 387 | 4.5 | 4.5~5.5 | 157 | 6.2 | 558 | 22.0 | 6.2 | 7.8/32 | 257 | BSW | - | - | - | |
13 inch |
* | 155/65R 13 | 73 | S | 805 | 365 | 4.5 | 4.5~5.5 | 157 | 6.2 | 532 | 20.9 | 6.2 | 7.8/32 | 244 | BSW | - | - | - |
* | 145/80R 13 | 75 | S | 853 | 387 | 4.0 | 3.5~5.0 | 145 | 5.7 | 562 | 22.1 | 6.5 | 7.8/32 | 255 | BSW | - | - | - |
※These data can be changed by the manufacturer without prior notice, and differently applied by regions.
* Available at the 2nd Quarter of 2013
